INCH-POUND
MIL-DTL-22499D
27 February 1998
Superseding
MIL-S-22499C
31 March 1989
DETAIL SPECIFICATION
SHIM STOCK, LAMINATED
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1.
SCOPE
1.1 Scope. This specification covers the requirements for surface bonded laminated shim stock.
1.2 Classification. Shim stock shall be of the following compositions, types, and classes, as specified in
the contract or purchase order (see 6.2):
Compositions:
Composition 1 - Aluminum alloy.
Composition 2 - Brass.
Composition 3 - Corrosion resisting steel.
Composition 4 - Carbon steel.
Composition 5 - Titanium alloy.
Composition 6 - Polyimide plastic.
Types:
Type 1
All laminations.
Type II
One-half solid stock.
Classes:
Class 1
.002 inch laminations.
Class 2
.003 inch laminations.
Beneficial comments (recommendations, additions, deletions and any pertinent data which may be
of use in improving this document should be addressed to: The Defense Industrial Supply Center,
Code DISC-AESD), 700 Robbins Avenue, Phila., PA 19111-5096, by using the Standardization
document Improvement Proposal (DD Form 1426), appearing at the end of this document or by letter.
AMSC N/A
FSC 9535
DISTRIBUTION STATEMENT A
Approved for public release: distribution is unlimited.
