MIL-DTL-22499D
TABLE II
Tolerances (thickness) on Composition 1, 2, 3, 4, 5 and 6.
Thickness
Tolerance
Tolerance
(Inch)
(plus)
(minus)
.006
.001
.0005
.008
.001
.0005
.010
.0015
.0005
.012
.0015
.001
.015
.0015
.001
.016
.0015
.001
.020
.002
.001
.021
.002
.001
.032
.003
.002
.033
.003
.002
.048
.005
.002
.062
.006
.002
.063
.006
.002
.078
.007
.002
.080
.007
.002
.093
.009
.003
.094
.009
.003
.109
.010
.003
.120
.012
.003
.121
.012
.003
.125
.012
.003
.156
.015
.003
.186
.018
.003
.187
.018
.003
.190
.018
.005
.233
.020
.005
.250
.025
.005
.251
.025
.005
.375
.030
.005
.376
.030
.005
