MIL-DTL-46027 Armor Plate, Aluminum Alloy, Weldable 5083, 5456, And 5059This specification covers weldable 5083, 5456, and 5059 wrought aluminum alloy armor plate in nominal thicknesses from 0.250 to 3.000 inch, inclusive \(see 6.2\).

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22 - 23

MIL-DTL-46027K(MR)

APPENDIX A

TABLE A-III. Minimum required ballistic limits � 20 mm fragment

simulating projectiles at 0� obliquity - (continued).

Thickness,

Required

Thickness,

Required

Thickness,

Required

inches

BL(P), fps

inches

BL(P), fps

inches

BL(P), fps

1.550

2531

1.610

2694

1.670

2867

1.555

2544

1.615

2708

1.675

2882

1.560

2558

1.620

2722

1.680

2897

1.565

2571

1.625

2737

1.685

2912

1.570

2585

1.630

2751

1.690

2928

1.575

2598

1.635

2765

1.695

2943

1.700 2/

1.580

2612

1.640

2780

2958

1.585

2625

1.645

2794

1.705

2973

1.590

2639

1.650

2809

1.710

2989

1.595

2653

1.655

2823

1.715

3004

1.600

2666

1.660

2838

1.720

3019

1.605

2680

1.665

2853

1.725

3035

Specification requirements end for this ordered thickness.
