MIL-DTL-46077 Armor Plate, Titanium Alloy, WeldableThis specification covers a weldable wrought titanium alloy structural armor plate in nominal thicknesses from 0.125 - 4.0 inch, inclusive. Ballistic data requirements for nominal thicknesses of 0.125 to 0.249 inch, inclusive are not available for this Revision.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22 - 23


MIL-DTL-46077G
Table 6. (cont.) Minimum Required V50 Ballistic Limits (Protection Criteria) (BL(P)).
Firing Obliquity: 0°
Projectile: 14.5-mm API B32
Required
Required
Required
BL(P)
Thickness
BL(P)
Thickness
BL(P)
Thickness
(fps)
(in)
(fps)
(in)
(fps)
(in)
1.950
3122
1.980
3154
2.010
3186
1.955
3128
1.985
3160
2.015
3191
1.960
3133
1.990
3165
2.020
3197
1.965
3138
1.995
3170
2.025
4003
1.970
3144
2.000
3176
2.030
4008
1.975
3149
2.005
3181
2.035
4013
11
