MIL-DTL-46077G

Table 5. (cont.) Minimum Required V50 Ballistic Limits (Protection Criteria) (BL(P)).

Firing Obliquity: 0�

Projectile: 20-mm FSP

Required

BL(P)

Thickness

BL(P)

Thickness

BL(P)

Thickness

(fps)

(in)

(fps)

(in)

(fps)

(in)

1.495

4413

1.550

4511

1.600

4601

1.500

4422

1.555

4520

1.605

4610

1.505

4431

1.560

4529

1.610

4619

1.510

4440

1.565

4538

1.615

4628

1.515

4449

1.570

4547

1.620

4637

1.5742

1.520

4458

4554

1.625

4646

1.525

4466

1.575

4556

1.630

4655

1.530

4475

1.580

4565

1.635

4664

1.535

4484

1.585

4574

1.640

4673

1.540

4493

1.590

4583

1.645

4682

1.545

4502

1.595

4592

1.650

4691

2 Specification requirements end with this ordered thickness (See Table 6).
